I/O Interfaces
Dual 10/100 Mbit Ethernet controllers
One USB port (routed via P2 with XVME-974 transition module)
Two high-speed serial ports (COM1, COM2 via XVME-974)
One EPP/ECP parallel port (via XVME-974)
Combined PS/2 keyboard/mouse port
Expansion
32-bit PMC site for custom I/O without carrier board
XVME-976 I/O carrier supports additional PMC, PC/104, PCI, and short-ISA modules
Power Consumption: Single-slot, low-power design (exact current not specified)
Form Factor: 6U single-slot VME card
Environmental Ratings
Operating Temperature: 0 °C to +70 °C (extended temp options available)
Storage Temperature: –40 °C to +85 °C
Humidity: 5 % to 95 % RH non-condensing
Functional Features
PC Compatibility: Runs Windows, Linux, VxWorks, QNX, and other PC operating systems with Xycom BSPs
PMC Expansion: Front-panel 32-bit PMC site enables high-speed custom I/O and FPGA cards
Multiple Storage Options: CompactFlash, hard-disk, floppy, or optical drives via simple plug-in modules
Rich Front-Panel I/O: Dual Ethernet, USB, serial, parallel, keyboard, mouse, and high-resolution graphics on bezel
Hot-Swap Ready: Conforms to VME64x hot-insertion specification
Low-Power Design: Optimized for fanless or minimal airflow applications, increasing MTBF
Application Scenarios
Industrial Automation: Central PLC or SCADA controller for chemical, automotive, and food-processing plants
Defense & Aerospace: Radar data servers, avionics test benches, and mission computers requiring PC software stacks
Test & Measurement: High-speed data acquisition and signal processing racks using standard PC tools and drivers
Energy & Utilities: Substation SCADA, turbine control, and renewable-energy inverter management nodes
