Xycom XVME-654

Power Consumption: +5 V @ 2.2 A typical

Form Factor: 6U single-slot, 233 mm × 160 mm

Environmental Ratings

Operating Temperature: 0 °C to +70 °C (forced-air)

Storage Temperature: –40 °C to +85 °C

Humidity: 5 % to 95 % RH non-condensing

Shock: 30 g operating / 50 g non-operating

Vibration: 2.5 g operating / 5 g non-operating

Functional Features

PC-Compatible Core: Ships with MS-DOS, Windows 95, or Windows NT pre-installed; supports Linux, VxWorks, and QNX via Xycom BSPs

PCI-to-VME Bridge: Enables DMA transfers and byte-swapping for high-speed data exchange

Hot-Swap Ready: Conforms to VME64x hot-insertion specification

Flexible Expansion: XVME-976 carrier adds PMC, PC/104, short-ISA, or PCI daughter cards

Front-Panel I/O: SVGA, keyboard, mouse, USB, serial, parallel, and Ethernet all on the bezel for rapid maintenance access

Self-Diagnostics: Power, CPU, and bus-activity LEDs plus watchdog timer for fault detection

Application Scenarios

Industrial Automation: High-speed PLC gateways, SCADA front-ends, and robot cell controllers

Defense & Aerospace: Radar data processors, launch-site telemetry, and avionics test benches

Transportation: On-board train control, wayside signaling, and toll-road data servers
