Resolution: 32-bit up/down counter per channel
VMEbus Interface: A16/A24, D16, interrupt-capable, programmable vector and level
Power Consumption: +5 V @ 900 mA typical
Form Factor: 6U single-slot VME64 standard; 233 mm × 160 mm
Operating Temperature: 0 °C to +70 °C
Storage Temperature: –40 °C to +85 °C
Humidity: 5 % to 95 % RH non-condensing
Functional Features
On-Board Intelligence: Local 68,000 CPU executes complex counting, timing, and motion-control algorithms without host intervention
Flexible Counting Modes
Up-count, down-count, quadrature, frequency, period, pulse-width, and time-interval measurements
Programmable Interrupts: Each channel can generate a VMEbus interrupt on terminal count, overflow, or external gate event
Real-Time Clock: 1 ms resolution time-base for accurate timestamping and synchronization
Front-Panel Indicators: LEDs for power, CPU status, and activity on each counter circuit
Jumper-Free Configuration: All parameters set via software-accessible registers
Battery-Backed Registers: Retains configuration and partial count data during power loss
Application Scenarios
Industrial Automation
High-resolution encoder feedback for multi-axis servo drives, packaging machines, and robotics
High-resolution encoder feedback for multi-axis servo drives, packaging machines, and robotics
Aerospace & Defense
Jet-engine turbine testing, missile fin position verification, and avionics actuator diagnostics
Jet-engine turbine testing, missile fin position verification, and avionics actuator diagnostics
Test & Measurement
Automated test equipment for frequency-response analysis, servo-loop validation, and stepper-motor characterization
Automated test equipment for frequency-response analysis, servo-loop validation, and stepper-motor characterization
Energy & Utilities
Turbine speed monitoring, generator phase-angle measurement, and substation power-quality analysis
Turbine speed monitoring, generator phase-angle measurement, and substation power-quality analysis
