Woodward 8200-1302

• Response Time: <10 ms
• Communication: RS-485, Ethernet, Modbus protocol
• Environmental Resistance:
  • Operating Temperature: -40°C to 85°C
  • Storage Temperature: -40°C to 85°C
  • Humidity: 5%–95% non-condensing
  • Protection Rating: IP65 (dust/water-resistant)
• Dimensions: 230 mm × 170 mm × 70 mm
• Weight: 3.5 kg

Key Features

• Triple Redundancy Design: Ensures uninterrupted speed control even if one component fails, enhancing system reliability.
• High-Precision Control: ±0.05% accuracy minimizes speed fluctuations, improving operational efficiency.
• Intuitive Interface: 8.4-inch LCD with navigation keys, soft keys, and LED status indicators for user-friendly operation.
• Multi-Mode Operation: Supports configuration, operation, and calibration modes for flexible system management.
• Critical Speed Avoidance: Three-speed-band critical speed avoidance prevents resonance during startup/shutdown.
• Event Logging: Real-time clock (RTC) timestamps alarms and trips for diagnostic traceability.
• Modular Design: Redundant speed inputs and configurable I/Os allow adaptation to diverse control requirements.

Functional Capabilities

• Automatic Start Sequences: Supports hot/cold starts with temperature input integration.
• Alarm Management: 10 external alarm inputs and 10 digital trip inputs for comprehensive fault detection.
• Dynamic Control: Dual-speed and load dynamics optimize performance under varying loads.
• Emergency Handling: Dedicated emergency trip button for instant shutdown in critical scenarios.

Applications

• Power Generation: Controls turbine speed in thermal/hydroelectric plants to maintain grid stability.
• Oil & Gas: Regulates compressor and pump speeds for safe upstream/downstream operations.
• Industrial Automation: Manages engine speeds in manufacturing processes requiring consistent power output.
• Marine Propulsion: Complies with ATEX and IACS UR E10 standards for shipboard turbine control.
• Water Treatment: Adjusts pump speeds to match demand, reducing energy consumption.

Industry Compliance

• Certifications: ATEX, IP54 (dust/water resistance), Pollution Degree 3.
• Standards: Meets IEC 61000-6-2 EMC immunity requirements for industrial environments.

Design Advantages

• Rugged Construction: Aluminum housing withstands vibration, shock, and electromagnetic interference.
• Compact Form Factor: Space-saving design simplifies integration into control panels.
• Global Usability: Operates in extreme temperatures (-40°C to 85°C) and high-humidity conditions.
