Tektronix 5A22N Arbitrary Waveform Generator
The Tektronix 5A22N Arbitrary Waveform Generator delivers laboratory-grade signal generation capabilities for precision testing applications. This dual-channel instrument excels in generating complex waveforms with exceptional amplitude and phase resolution, making it ideal for electronic design validation, component testing, and system calibration.
| Brand | Tektronix |
| Frequency Range | Up to 50 MHz |
| Waveform Memory | 16 kpts/channel |
| Vertical Resolution | 14-bit |
| Output Amplitude | ±10 Vpp |
| Phase Resolution | 0.088° |
Typical Applications
- Power electronics testing
- Communication system simulation
- Sensor signal emulation
- Automated test system integration
Commonly paired with Tektronix TDS3000 series oscilloscopes and Keithley 2400 source meters for complete test solutions.
Vertex Industrial Advantage
As specialists in industrial automation solutions, we provide:
- 1-year performance warranty
- Pre-sales technical consultation
- Global logistics support
- Custom procurement services
Need specific configuration or bulk pricing? Contact our engineers via WhatsApp for immediate assistance.
