GE DS3800NFCD1S1L

The board has 44 integrated circuits, including an Intel 8243 input/output expander with four 4 - bit I/O ports, dual D - type positive edge - triggered flip - flops (SN 74LS74AN), and dual J - K flip - flops from Motorola (SN 74LS112AN).
It features two dip plugs (Augat), one vertical 5 - pin male connector, and two 218 A 4537 - P 4 connectors located on the right board edge.
The board is populated with two plunge switches, over twenty transistors, and thirty test points.
It has fifteen LEDs, with seven red LEDs in the upper left quadrant, one amber LED, and seven red LEDs in the lower left quadrant.
There are also four jumper switches (one of which is multi - positional) and three ammeters.

Tag：

Functional Features:

It acts as a motherboard for the smaller DS3800 DFC D, providing additional components access when attached.
The input/output expander and flip – flops play important roles in signal processing and storage, helping to manage the data flow and status within the system.

Application Scenarios:
The DS3800NFCD1S1L is used in the Mark IV system, which is developed for gas and steam turbine management. It can protect turbine systems from operating outside of safe parameters and automate startup, cooldown, and shutdown procedures.
