Allen-Bradley 1769-ADN CompactLogix Analog Input Module
The Allen-Bradley 1769-ADN Analog Input Module delivers high-precision signal acquisition for industrial automation systems. Engineered for seamless integration with Rockwell Automation platforms, this module converts analog sensor signals into digital data for process monitoring and control applications across manufacturing, energy, and processing industries.
| Parameter | Specification |
|---|---|
| Brand | Allen-Bradley (A-B) |
| Model | 1769-ADN |
| Series | 1769 Compact I/O |
| Input Channels | 8 channels |
| Input Voltage Range | ±10V, ±5V |
| Resolution | 16-bit |
| Sampling Rate | 100 Hz per channel |
| Dimensions | 10 x 10 x 6 cm |
| Weight | 0.2 kg |
| Certifications | CE, UL, CSA |
Applications & System Integration
Designed for Allen-Bradley ControlLogix and CompactLogix systems, this module is ideal for:
• Process variable monitoring (temperature, pressure, flow rate)
• Production line quality control systems
• Energy management and equipment health monitoring
• Seamless integration with 1769 backplanes and DeviceNet networks
Compatible with sensors from Rosemount, Endress+Hauser, and other major industrial instrumentation brands.
Vertex Industrial Services
Vertex Industrial sources premium industrial automation components from global suppliers. Our technical team provides:
- Pre-sales consultation – System integration guidance and compatibility verification
- 1-year warranty – Comprehensive after-sales support on all components
- Global sourcing – Access to 200,000+ industrial parts across 40+ brands
- Custom procurement – Can’t find your model? Contact us via WhatsApp for special requests
Pricing & Availability: Contact our team for real-time quotes and lead times:
• Email: anikaqx@gmail.com
• WhatsApp: +86 136 3952 2374
