ABB 3BHE037864R0104

Technical Specifications

1. Power Supply & Consumption
   • Dual redundant power input: DC 9–36V (typical DC 24V),功耗 <4W.
   • DC 1500V voltage isolation and reverse polarity protection.
   • Industrial terminal interface.
2. Relay Alarm Outputs
   • Fiber-optic link failure and power failure alarms.
   • Contact capacity: DC 48V/1A, industrial terminal interface.
3. Mechanical & Environmental
   • Dimensions: 132mm × 105mm × 52mm.
   • Enclosure: IP30-rated aluminum case with corrugated texture.
   • Mounting: 35mm DIN rail.
   • Weight: 800g.
   • Operating temperature: -10°C to 70°C (wide-temperature option: -40°C to +85°C).
   • Humidity: ≤90% non-condensing.
   • Storage temperature: -40°C to 80°C.
4. Certifications
   • Complies with EN55022:2010, EN61000-4-2:2001, EN61000-4-3:2006.
   • EMC testing includes ESD (±8kV air, ±4kV contact) and RF immunity (3V/m, 80–1000MHz).

Functional Features

1. High-Performance Computing
   • Equipped with advanced processors for complex control tasks and real-time processing.
   • Large RAM capacity supports multitasking and multithreading.
2. Expandability & Connectivity
   • Multiple expansion slots (PCI, PCIe) for adding function cards (e.g., communication interfaces).
   • Rich I/O interfaces: digital/analog I/O, Ethernet, serial ports, and fiber-optic links.
3. Reliability & Durability
   • Designed for harsh industrial environments with shock resistance, temperature extremes, and corrosion resistance.
   • Complies with industrial standards (e.g., IEC 61131-2).
4. Operating System & Management
   • Supports real-time operating systems (RTOS) for deterministic performance.
   • Remote management capabilities for monitoring, configuration, and maintenance.
   • Low-power design reduces energy consumption and heat generation.

Application Scenarios

1. Industrial Automation
   • Used in manufacturing for controlling machinery, production lines, and robotic systems.
   • Integrates with ABB’s AC800 PEC controllers and other automation systems.
2. Energy Management
   • Monitors and controls energy distribution systems, including renewable energy integration.
   • Supports grid stability in power generation and transmission.
3. Transportation Systems
   • Manages traffic signals, railway signaling, and fleet logistics.
   • Enhances reliability in critical infrastructure.
4. Building Automation
   • Controls HVAC, lighting, and security systems in commercial buildings.
   • Facilitates smart building integration via Ethernet and BACnet protocols.
5. Process Control
   • Deployed in chemical, pharmaceutical, and food processing industries for precise parameter control.
   • Works with ABB’s 800xA DCS for seamless process optimization.

Additional Notes

• Installation: Follow ABB’s guidelines for DIN rail mounting and proper wiring.
• Maintenance: Regular inspections and firmware updates are recommended.
• Compatibility: Designed to integrate with ABB’s UFC911B, PPD113, and other modular control systems.
